Engine

R 214TC RIDER C94

Art no: 970 54 23‑01

Power/fuel type

Petrol

Net power at preset rpm Energy

¹

12 kW

Net power at preset rpm

2,900 rpm

Engine brand

Husqvarna

Motor/engine manufacturer

Husqvarna

Engine name

HV 586AE

Cylinder displacement

586 cm³

Cylinders

2

Engine cooling

Air

Engine lubrication type

Pressure with Oilfilter

Oil filter

Yes

Emission

Exhaust emissions (CO₂ EU V)

²

778 g/kWh

Battery

Battery capacity

24 Ah

Battery type

Lead-Acid

Battery pack weight

7.2 kg

Battery manufacturer

Global

Cutting deck

Uncut circle

30 cm

Cutting width, min

94 cm

Cutting width, max

94 cm

Cutting height min

25 mm

Cutting height max

75 mm

Blade engagement

Automatic

Dimensions

Tyre dimensions, front

170/60-8

Tyre dimensions, rear

170/60-8

Wheelbase

88.7 cm

Ground clearance

105 mm

Base machine, length

223 cm

Base machine, width

100 cm

Base machine, height

107 cm

Gross weight towed

³

110 kg

Weight (excl. cutting equipment)

207 kg

Drive system

PTO (Power Take Off)

Belt-driven

Transmission type

Hydrostatic

Drive method

Dual pedal-operation

Speed forward max

9 km/h

Speed reverse max

6 km/h

Equipment

Seat suspension

Yes

Seat type

Comfort

Hour meter type

Digital

Seat material

PU

Seat back height

High

Foldable seat

Yes

Steering wheel type

Ergonomic

Parking brake, type

Disc

Vibration

Vibration level steering wheel

1.9 m/s²

Vibration level seat

0.29 m/s²

Sound and noise

Sound pressure level at operators ear

83 dB(A)

Sound power level, guaranteed (LWA)

98 dB(A)

Sound power level, measured

97 dB(A)
